SG-2050AH Saddle Moving Type Grinder The Ideal Solution for Precision Surface Grinding

Name: SG2050AH Saddle Moving Type Grinder The Ideal Solution for Precision Surface Grinding
Brand: TIMEWAU
Price: 13 USD

Quality SG-2050AH Saddle Moving Type Grinder The Ideal Solution for Precision Surface Grinding for sale

CNC or Not : Normal

Condition : New

Grinding Length(mm) : 1130

Surface Roughness(μm) : 3.2 μm

Year : 2023

Place of Origin : China

Brand Name : TIMEWAU

Voltage : 220/380V

Weight (KG) : 3200

Power (kW) : 4

Warranty : 1 Year

Key Selling Points : High Productivity

Showroom Location : India, Mexico, Egypt, South Korea, Thailand, Brazil, Saudi Arabia, United States

Marketing Type : Ordinary Product

Machinery Test Report : Provided

Video outgoing-inspection : Provided

Warranty of core components : 1 Year

Core Components : Motor, Bearing, Gearbox, Pressure vessel, Pump

Applicable Industries : Manufacturing Plant, Energy & Mining, Machinery Repair Shops, Building Material Shops

Type : Surface Grinding Machine

Product name : Surface Grinder Grinding Machine

Name : Grinder Machine

Application : Stainless Steel

Usage : Surface Polishing

Keywords : Precision Surface Grinder Machine

Function : Grinding Material

Certification : CE ISO

Machine Type : Suface Grinding Machine

Processing : Surface Grinder Surface Grinding Machine

Packaging Details : Wooden cases(can be fumigated)

Port : China Port

Supply Ability : 150 Set/Sets per Month

Price : $13,000.00/sets 1-2 sets

MOQ : 1 set

Contact Now

Products Description

SG-2050AH Saddle Moving Type Grinder The Ideal Solution for Precision Surface Grinding

Specification	Unit	SG-30100AH SG-30100AHR SG-30100AHD	SG-4080AH SG-4080AHR SG-4080AHD	SG-40100AH SG-40100AHR SG-40100AHD
Table size	mm	305x1020	406x813	406x1020
Electro magnetic chuck size	mm	300x1000	400x800	400x1000
Distance from spindle to table	mm	580	580	580
Table cross travel	mm	340	450	450
Table longitudinal travel	mm	1130	910	1130
Loading capacity (include chuck)	kg	400	500	600
Longitudinal feed speed	m/min	5-25	5-25	5-25
Table cross intermittent feed rate	mm/str	0.1-8	0.1-8	0.1-8
Table cross rapid feed speed	mm/min	990	990	990
Table cross feed of handwheel	mm/gra	0.02	0.02	0.02
Wheelhead vertical intermittent feed rate	mm/str	AH: -; AHR: -; AHD: 0.005-0.5;	AH: -; AHR: -; AHD: 0.005-0.5;	AH: -; AHR: -; AHD: 0.005-0.5;
Wheelhead vertical rapid feed speed	mm/min	AH: -; AHR: 650; AHD: 480;	AH: -; AHR: 650; AHD: 480;	AH: -; AHR: 650; AHD: 480;
Wheelhead vertical feed of handwheel	mm/gra	0.005	0.005	0.005
Spindle speed (50/60HZ)	rpm	1450/1750	1450/1750	1450/1750
Grinding wheel size	mm	350x40x127	350x40x127	350x40x127
Main motor power	kw	4	4	4
Machine dimensions (LxWxH)	cm	440x220x190	360x240x190	440x240x190
Package dimensions (LxWxH)	cm	295x222x221	285x227x221	295x227x221
Machine weight	kg	3200	3400	3700

Operation manual (English edition)	Balancing stand
Working lamp	Magnetic separator
Balancing arbor	Paper filter
Standard grinding wheel	Oil tank guard
Magnetic chuck	Dust exhaust
Built-in magnetic chuck controller	Parallel wheel dresser
Coolant tank	2 axis digital readout
Wheel flange and extractor	Extra wheel flange
Wheel dresser stand
Leveling wedge and screw
Lubrication system
Tool box & tools

Why Choose Us

Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price;
2 . Professional R&D team and 25 years export experience;
3 . Exported more than 60 countries;
4 . CE, ISO Certificates;
5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager);
6 . 12 months quality warranty;
7 . Oversea engineers available for problem resolving;

Q: Do you have QC or any safety standards for your machinery?
A: yes, we have established a highly strict quality control department to guanrantee good quality.

Q: What's the MOQ?
A: 1 set (Only some low cost machines will be more than 1 set )

Q: What about the payment terms?
A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment;
(2) Irrevocable LC at sight;
(3) Western Union, MoneyGram, etc.

Q: How about the warranty?
A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.

SG-2050AH Saddle Moving Type Grinder The Ideal Solution for Precision Surface Grinding Images
