2.2kW Power SG-2050AH Saddle Mobile Surface Grinding Machine for High Precision Grinding

Name: 22kW Power SG2050AH Saddle Mobile Surface Grinding Machine for High Precision Grinding
Brand: TIMEWAY
Price: 8 USD

Quality 2.2kW Power SG-2050AH Saddle Mobile Surface Grinding Machine for High Precision Grinding for sale

CNC or Not : Normal

Condition : New

Grinding Length(mm) : 450

Wheel Size(mm) : 200310315

Surface Roughness(μm) : 3.2 μm

Table Size(mm) : 200x508

Table Travel (X) (mm) : 240

Table Travel (Y) (mm) : 560

Year : 2023

Place of Origin : Henan, China

Brand Name : TIMEWAY

Voltage : 220/380V

Dimension(L*W*H) : 2300x1600x1680

Weight (KG) : 1650

Power (kW) : 2.2

Warranty : 1 Year

Key Selling Points : High Productivity

Showroom Location : South Korea, Thailand, Brazil, Saudi Arabia, United States

Marketing Type : Ordinary Product

Machinery Test Report : Provided

Video outgoing-inspection : Provided

Warranty of core components : 1 Year

Core Components : Motor, Bearing, Gearbox, Engine, Gear

Applicable Industries : Manufacturing Plant, Energy & Mining, Machinery Repair Shops

Type : Surface Grinding Machine

After-sales Service Provided : Provided

Product name : Surface Grinder Grinding Machine

Application : Stainless Steel

Name : Grinder Machine

Usage : Surface Polishing

Keywords : Precision Surface Grinder Machine

Function : Grinding Material

Certification : CE ISO

Machine Type : Suface Grinding Machine

Price : $8,000.00/sets 1-2 sets

MOQ : 1 set

Contact Now

Products Description

SG-2050Series

Saddle Moving Type Surface Grinder:

2.2kW Power SG-2050AH Saddle Mobile Surface Grinding Machine for High Precision Grinding

SPECIFICATION	UNIT	SG-2050AH SG-2050AHR SG-2050AHD
Table size	mm	200x508
Electro magnetic chuck size	mm	200x460
Distance from spindle to table	mm	450
Table cross travel	mm	240
Table longitudinal travel	mm	560
Loading capacity (include chuck)	kg	180
Longitudinal feed speed	m/min	5-25
Table cross rapid feed speed	mm/min	990
Table cross micro feed rate	mm/gra	0.002
Wheelhead vertical rapid feed speed	mm/str	AH: -; AHR: -; AHD: 0.005-0.5;
Wheelhead vertical micro feed rate	mm/min	AH: -; AHR: 650; AHD: 480;
Spindle speed (50/60HZ)	rpm	2850/3450
Grinding wheel size	mm	200x20x31.75
Main motor power	kw	2.2
Machine dimensions (LxWxH)	mm	2300x1600x1680
Package dimensions (LxWxH)	mm	2000x2100x2150
Machine weight	kg	1650

Positive Comments From Customers

Shipping

Exhibitions

TIMEWAY at EMO Hannover

TIMEWAY machine participates in the EMO Hannover exhibition every time, which is Europe's leading machine tool and metal processing technology exhibition. At the exhibition, TIMEWAY machine demonstrated its advanced machine tools and processing technology, as well as comprehensive solutions for different industries and application fields. These solutions include precision machining and production of high-quality metal parts for the automotive, aerospace, energy, and other sectors.

TIMEWAY at CIMT

CIMT is held in China, the hometown of TIMEWAY machine, so TIMEWAY machine will participate in the CIMT exhibition every time. This is the China International Machine Tool Exhibition and one of the largest machine tool exhibitions in Asia. At the exhibition, TIMEWAY displayed its diversified machine tool products, including CNC machine tools, machining centers, gear processing machine tools, precision measuring equipment, etc.

TIMEWAY at Metalloobrabotka

TIMEWAY participated in the Metalloobrabotka exhibition held in Moscow, which is a professional exhibition for the metal processing and machine tool industry in Russia and surrounding areas. At the exhibition, TIMEWAY's booth attracted the attention of many exhibitors and industry experts. The company's professional team had in-depth exchanges with exhibitors and visitors from Russia and other countries and regions, sharing valuable experience and the latest industry trends. In addition, TIMEWAY machine has also participated in exhibitions in many countries and regions.

Company Introduction

Factory Display：

Text Introduction：

Company Profile：

Timeway Machine Tool Co., Ltd. is a professional machine tool manufacturing enterprises, the main products include lathe, milling machine, grinding machine, etc., and according to customer needs we also can design and manufacture various special purpose machines, to provide relative technology upgrading and transformation services in machine tool field.

Our factory was established in 2014. It has professional technicians, a research and development team, manufactures and sells CNC equipment and provides professional customized services.Our products are widely used in mold processing, 3C products, agricultural machinery, petroleum machinery, auto parts processing, aerospace industry, etc., selling more than 60 countries and regions in domestic and abroad.

FAQ

Q: Why choose TIMEWAY MACHINE?

A: 1 . High quality with competitive price; 2 . Professional R&D team and 25 years export experience; 3 . Exported more than 60 countries; 4 . CE, ISO Certificates; 5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager); 6 . 12 months quality warranty; 7 . Oversea engineers available for problem resolving; Q: Do you have QC or any safety standards for your machinery? A: yes, we have established a highly strict quality control department to guanrantee good quality. Q: What's the MOQ? A: 1 set (Only some low cost machines will be more than 1 set ) Q: What about the payment terms? A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment; (2) Irrevocable LC at sight; (3) Western Union, MoneyGram, etc. Q: How about the warranty? A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.

2.2kW Power SG-2050AH Saddle Mobile Surface Grinding Machine for High Precision Grinding Images
