Highly Manual Rotary Surface Grinding Machine With Vertical Spindle 1000x1050x1620mm

Name: Highly Manual Rotary Surface Grinding Machine With Vertical Spindle 1000x1050x1620mm
Brand: TIMEWAY
Price: 11 USD

Quality Highly Manual Rotary Surface Grinding Machine With Vertical Spindle 1000x1050x1620mm for sale

Type : Universal, Vertical Spindle Rotary Surface Grinding Machine

CNC or Not : Normal

Condition : New

Wheel Size(mm) : 150x70x32

Year : 2023

Place of Origin : China

Brand Name : TIMEWAY

Voltage : Customized

Dimension(L*W*H) : 1000x1050x1620mm

Weight (KG) : 880

Power (kW) : 3

Warranty : 1 Year

Key Selling Points : Competitive Price

Showroom Location : UAE, Mexico, Kenya, Australia, Japan, Spain, Egypt, Russia, Turkey, Peru, Thailand, Chile, Brazil

Applicable Industries : Manufacturing Plant, Construction works

Marketing Type : Ordinary Product

Machinery Test Report : Provided

Video outgoing-inspection : Provided

Warranty of core components : 1 Year

Core Components : Motor

Grinding wheel size : 150x70x32mm

Max. weight of workpiece : 40kg

After-sales Service Provided : Online Support

Application : Metal Processing

Model : VSG-320A

Machine Type : Manual

Max. Grinding area : 320x100mm

COLOR : Customized Optional

Packing size : 1000x1050x1620mm

Packaging Details : Wooden cases(can be fumigated)

Port : China Port

Supply Ability : 150 Set/Sets per Month

Price : $11,533.00/sets 1-2 sets

MOQ : 1 set

Contact Now

Products Description

Highly Manual Rotary Surface Grinding Machine With Vertical Spindle 1000x1050x1620mm

Specification	Unit	VSG-320A
Max. grinding size	mm	320x200
Worktable rotary dia.	mm	320
Distance from table center to grinding head center	mm	0-60
Max. distance from lower end surface of wheel to table	mm	160
Worktable speed	r/min	46
Wheelhead spindle speed	r/min	2850-3000
Whealhead rapid moving speed	mm/min	70
Grinding head adjust angle	º	±18
Grinding wheel size	mm	150x70x31.5
Max. weight of workpiece	kg	40
Wheel head motor power	kw	4
Worktable rotary motor	kw	0.25
Coolant motor	kw	0.06
Total motor power	º	±45º~-30º
Machine weight	kg	1700
Packing size (LxWxH)	mm	1250x800x1900

Why Choose Us

Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price;
2 . Professional R&D team and 25 years export experience;
3 . Exported more than 60 countries;
4 . CE, ISO Certificates;
5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager);
6 . 12 months quality warranty;
7 . Oversea engineers available for problem resolving;

Q: Do you have QC or any safety standards for your machinery?
A: yes, we have established a highly strict quality control department to guanrantee good quality.

Q: What's the MOQ?
A: 1 set (Only some low cost machines will be more than 1 set )

Q: What about the payment terms?
A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment;
(2) Irrevocable LC at sight;
(3) Western Union, MoneyGram, etc.

Q: How about the warranty?
A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.

Highly Manual Rotary Surface Grinding Machine With Vertical Spindle 1000x1050x1620mm Images
