Powerful 4kW Universal Cylindrical Grinding Machine UG-200 G-320 for Precise Grinding

Name: Powerful 4kW Universal Cylindrical Grinding Machine UG200 G320 for Precise Grinding
Brand: TIMAC
Price: 50 USD

Quality Powerful 4kW Universal Cylindrical Grinding Machine UG-200 G-320 for Precise Grinding for sale

Grinding Diameter(Outer)(mm) : 500

Grinding Diameter(Inner)(mm) : 200

Grinding Length(mm) : 750

Max. Length of Workpiece (mm) : 3000

Max. Weight of Workpiece(kg) : 200

Center Height (mm) : 135

Wheel Size(mm) : 400x50x203

Wheel Speed (rpm) : 380

Table Travel (X) (mm) : 50

Table Travel (Y) (mm) : 205

Surface Roughness(μm) : 0.4

Place of Origin : China

Brand Name : TIMAC

Voltage : 220V/380V

Dimension(L*W*H) : as require

Weight (KG) : 3000

Power (kW) : 4

Key Selling Points : Competitive Price

Warranty : 1 Year

Showroom Location : Romania, Australia, Canada, United States, United Kingdom

Applicable Industries : Manufacturing Plant, Building Material Shops, Advertising Company

Marketing Type : New Product 2020

Machinery Test Report : Provided

Video outgoing-inspection : Provided

Warranty of core components : 1 Year

Core Components : Motor, Bearing, Gearbox, Engine, Gear, Pressure vessel, Pump, Other

Condition : New

CNC or Not : Normal

Function : Grinding

Keyword : Standard Cylindrical Grinder

Warranty period : 1 year

Distance between centers : 500/750mm

Max. length ground (O.D) : 500/750mm

Max. length ground (I.D) : 100mm

Center height : 135

Roughness of the surface : Ra0.40

Dia. Ground (O.D) : 5-200

Dia. Ground (I.D) : 25-100

Packaging Details : Wooden case(Can be fumigated)

Supply Ability : 300 Set/Sets per Month

Price : $50,000.00/sets 1-2 sets

MOQ : 1 set

Contact Now

Universal Cylindrical Grinding Machine UG-200, G-320

Powerful 4kW Universal Cylindrical Grinding Machine UG-200 G-320 for Precise Grinding

Model		Unit	G-200	UG-200	G-320	UG-320
General capacity
Distance between centers		mm	500/750	500/750	1000/1500/2000/3000	1000/1500/2000/3000
Center height		mm	135	135	180	180
Dia. Ground (O.D)		mm	5-200	5-200	8-320	8-320
Dia. Ground (I.D)		mm	-	25-100	-	30-100
Max. length ground (O.D)		mm	500/750	500/750	1000/1500/2000/3000	1000/1500/2000/3000
Max. length ground (I.D)		mm	-	100	-	125
Max weight of work piece		Kg	-	100	150	150
Workhead
Swiveling angle		°	-	+90 °	-	+90 °
Center taper (MT)		MT	4	4	5	4
Spindle speed		r/min	50HZ:25-380	50HZ:25-380	26,52,90,130,180,260	50HZ:25-220
Wheel head
Wheel spindle speed		rpm	1335	1670	110	1670
Wheelhead rapid travel		mm	50	50	50	50
Max. travel		mm	205	205	235	246
Swiveling angle		°	-	±30°	-	±30°
Wheel size(ODxWxID)		mm	500x50x203	400x50x203	600x63x305	400x50x203
Peripheral speed		m/s	35	35	35	35
Internal grinding device
Spindle speed		r/min	-	10000	-	10000
Wheel size		mm	-	Max:35x25x10, Min:17x20x6	-	Max:50x25x13, Min:17x20x6
Table
Hand feed per. rev		mm	6	6	6	6
Max. swiveling angle	clockwise	°	3 °	3 °	3 °(1000/1500)/2 °(2000/3000)
Max. swiveling angle	anticlockwise	°	9 °(500)/8 °(750)		7°(1000)/6°(1500)/5°(2000)/3°(3000)
Longitudinal feed speed		m/min	0.1-4	0.1-4	0.1-4	0.1-4
Tailstock
Center tape (MT)		MT	4	4	4	4
Quill travel		mm	30	30	30	30
Motor
Wheelhead motor power		kw	5.5	4	11	5.5
Internal grinding		kw	-	1.1	-	1.1
Workhead motor power		kw	0.75	0.75	0.75/1.5	1.5
Machine
Gross weight		T.	4/4.2	4.1/4.3	5.3/6.1/7.9/9.9
Packing dimension		cm	260/300x203x205	260/300x203x205	322/422/540/739x200x205
