Manufacturing Plant Universal Knee-Type Milling Machine With Swivel Head Weight KG 2900

Table Travel (X) (mm) : 700

Machining Capacity : Medium Duty

Table Travel (Y) (mm) : 255

Table Travel (Z) (mm) : 320

Spindle Taper : ISO50

Range of Spindle Speed(r.p.m) : 60 - 1750 r.p.m

Place of Origin : China

Brand Name : TIMEWAY

Model Number : US320H

Type : Universal

Spindle Motor Power(kW) : 4

Voltage : optional

Dimension(L*W*H) : 2294x1770x1780mm

Weight (KG) : 2900

Warranty : 1 Year

Key Selling Points : High Productivity

Marketing Type : Hot Product 2019

Machinery Test Report : Provided

Video outgoing-inspection : Provided

Warranty of core components : 1 Year

CNC or Not : Normal

Name : Swivel head knee-type milling machine

After Warranty Service : Online support

Certification : ISO

Table size : 320x1325mm

After-sales Service Provided : Online Support

X-axis travel : 700mm

Y-axis travel : 255mm

Z-axis travel : 320mm

Spindle Speed : 60-1750rpm

Number of Axes : 3

Condition : New

Applicable Industries : Manufacturing Plant, Construction works

Showroom Location : Kenya, South Korea, Chile, UAE, Ukraine, Uzbekistan, Japan, Egypt, United Kingdom, United States, Italy, Philippines, Brazil, Pakistan

Table Travel (mm) : 700

Year : 2023

Core Components : Motor, Other

Packaging Details : wooden case

Port : China port

Supply Ability : 100 Set/Sets per Month

Price : $15,980.00/sets 1-2 sets

MOQ : 1 set

Contact Now

Product Paramenters
Manufacturing Plant Universal Knee-Type Milling Machine With Swivel Head Weight KG 2900
Manufacturing Plant Universal Knee-Type Milling Machine With Swivel Head Weight KG 2900
Specification
Unit
US320H
Worktable size
mm
320x1325
T-slot(NxWxD)
mm
3/18/70
Distance from vertical spindle nose to table
mm
190-510
Longitudinal travel(X)
mm
700
Cross travel(Y)
mm
255
Vertical travel(Z)
mm
320
X/Y/Z-axis rapid feed speed
mm/min
2300/2300/770
Feed speed range(X)
mm/min
23.5-1180 (18)
Feed speed range(Y)
mm/min
23.5-1180 (18)
Feed speed range(Z)
mm/min
8-394 (18)
Mill head swivel angle
°
360
Worktable swivel angle
°
45
Main motor power
kw
4
Dimensions (LxWxH)
mm
2294x1770x1780
Machine Weight
kg
2900
Manufacturing Plant Universal Knee-Type Milling Machine With Swivel Head Weight KG 2900
- Draw bar
- Horizontal mill arbor
- Coolant system
- Chip tray
- Work lamp
- Lubrication system
- Tools & Tool-box
- operation manual
- 2/3-axis DRO
- 58pcs clamping kit
- Machine vise
- Spindle protection guard
- Dividing head
- Rotary table
- Reducing sleeve
Company Introduction
Manufacturing Plant Universal Knee-Type Milling Machine With Swivel Head Weight KG 2900
Package & Transportation
Manufacturing Plant Universal Knee-Type Milling Machine With Swivel Head Weight KG 2900
Customers Visited
Manufacturing Plant Universal Knee-Type Milling Machine With Swivel Head Weight KG 2900
Exhibition & Training
Manufacturing Plant Universal Knee-Type Milling Machine With Swivel Head Weight KG 2900
Export Cases
Manufacturing Plant Universal Knee-Type Milling Machine With Swivel Head Weight KG 2900
Our Team
Manufacturing Plant Universal Knee-Type Milling Machine With Swivel Head Weight KG 2900
FAQ
Q: Why choose TIMEWAY MACHINE? A: 1 . High quality with competitive price; 2 . Professional R&D team and 25 years export experience; 3 . Exported more than 60 countries; 4 . CE, ISO Certificates; 5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager); 6 . 12 months quality warranty; 7 . Oversea engineers available for problem resolving; Q: Do you have QC or any safety standards for your machinery? A: yes, we have established a highly strict quality control department to guanrantee good quality. Q: What's the MOQ? A: 1 set (Only some low cost machines will be more than 1 set ) Q: What about the payment terms? A: 1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment; 2) Irrevocable LC at sight; 3) Western Union, MoneyGram, etc. Q: How about the warranty? A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
