High Productivity Vertical Milling Machine with Adjustable Spindle-Table Distance

Type : Universal

CNC or Not : Normal

Condition : New

Place of Origin : Henan, China

Brand Name : Timeway/TIMAC

Dimension(L*W*H) : 230*1067

Weight (KG) : 1060

Power (kW) : 2.2

Warranty : 1 Year

Key Selling Points : High Productivity

Showroom Location : India, Japan, Spain, Egypt, Russia, Turkey, Italy

Applicable Industries : Manufacturing Plant, Construction works , Energy & Mining, Machinery Repair Shops, Building Material Shops

Marketing Type : Hot Product 2020

Machinery Test Report : Provided

Video outgoing-inspection : Provided

Warranty of core components : 1 Year

Core Components : Motor, Engine, Pump

Product name : turret milling machine

Model : M230B

Longitudinal travel : 610/790mm

Cross travel : 310mm

Vertical travel : 390mm

Ram travel : 315mm

Distance from spindle to table : 0-350

Spindle taper : R8

Spindle quill travel : 127mm

Main motor power : 2.2kw

Price : $14,900.00/sets 1-2 sets

MOQ : 1 set

Contact Now

Product Description
Vertical Turret Milling Machine
M230A/M230B
High Productivity Vertical Milling Machine with Adjustable Spindle-Table Distance

Feature:

M230A:
*Double 55°dovetail guide way is adopted on Both Y and Z axis;
*Adopted strengthen rib on both sides of the column;
*The work table surface and 3 axis guide way are hardened and precision ground.

M230B:
*Double 55°dovetail guide way is adopted on Z axis, and rectangular guide way on Y axis;
*Adopted strengthen rib on both sides of the column;
*The work table surface and 3 axis guide way are hardened and precision ground.
Specification
SPECIFICATION
UNIT
M230A
M230B
Table size
mm
230x1067/230x1246
230x1067/230x1246
Longitudinal travel(X)
mm
670/850
610/790
Cross travel(Y)
mm
310
310
Vertical travel(Z)
mm
390
390
Ram travel
mm
315
315
Distance from spindle to table
mm
0-350
0-350
Spindle taper
-
R8(Optional :ISO30/ISO40)
R8(Optional : ISO30/ISO40)
Spindle quill travel
mm
127
127
Spindle speed
rpm
16steps, 50HZ: 65-4500/60HZ: 80-5440 (Optional: Variable 60-4200)
Spindle quill automatic feed
mm/r
0.038/0.076/0.152
0.038/0.076/0.152
Main motor power
kw
2.2
2.2
Mill head swivel angle
°
±90°
±90°
Mill head tilting angle
°
±45°
±45°
X/Y/Z-axis guide type
-
▲▲▲
▲■▲
Dimension of package(One)
mm
1400x1476x2030
1400x1476x2030
Dimension of package(Two)
mm
1450x1570x2080
1450x1570x2080
Dimension of package(Three)
mm
1450x2180x2080
1450x2180x2080
Gross weight (One)
kg
1000
1060
Accessories

Standard accessories:

* Draw bar
* Electric box
* Working light
* Hand oil pump
* Tool & tool box

Optional accessories:

* Digital readout system(DRO)
* Machine vise
* Power feed unit
* Gear box power feed
* Clamping kits
* ISO40 collet chuck
* R8 collet chuck
* Oil collecting plate
* Plastic splash guard
* Cooling system
