Fresadora BM718 High Precision CNC Bed Milling Machine for Professional Machining

Table Travel (X) (mm) : 2500

Machining Capacity : Heavy Duty

Table Travel (Y) (mm) : 820

Table Travel (Z) (mm) : 1090

Spindle Taper : ISO50

Range of Spindle Speed(r.p.m) : 2.5 - 3000 r.p.m

Place of Origin : China

Brand Name : TIMEWAY

Model Number : BM718

Type : Universal

Weight (KG) : 10000

Warranty : 1 Year

Key Selling Points : Multifunctional

Marketing Type : New Product

Machinery Test Report : Provided

Video outgoing-inspection : Provided

Warranty of core components : 1 Year

CNC or Not : Normal

Product name : Milling Machine

Machine Type : Metal Milling Machine

After-sales Service Provided : Online Support

Name : 3 Axis Milling Machine

Keyword : Fresadora

Usage : Processing Machine

Precision : High Precision

Processing : Metal Vertical Milling Machine

Color : Customized Option

Number of Axes : 3

Condition : New

Applicable Industries : Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Construction works

Showroom Location : Morocco, Kenya, Argentina, South Korea, Chile, UAE, Algeria, Japan, Canada, Turkey, United Kingdom, United States, Italy, France, Germany, Viet Nam, Indonesia, Mexico

Core Components : Bearing, Motor, Pump, Gear, PLC, Pressure vessel, Engine, Other, Gearbox

Packaging Details : Wooden cases(can be fumigated)

Port : China Port

Supply Ability : 150 Set/Sets per Month

Price : $42,000.00/sets 1-2 sets

MOQ : 1 set

Contact Now

Products Description
BM718
Bed Type Milling Machine:
Fresadora BM718 High Precision CNC Bed Milling Machine for Professional Machining
Fresadora BM718 High Precision CNC Bed Milling Machine for Professional Machining
SPECIFICATIONS
UNIT
BM718
Table size
mm
700x2800
Longitudinal travel (X)
mm
2500
Cross travel (Y)
mm
820
Vertical travel (Z)
mm
1090
T slot (No./width/distance)
mm
4/20/100
Loading capacity
kg
5000
Spindle taper
ISO50
Spindle speed
rpm
36-1340（12)
Distance from spindle axis to table
mm
385-1540/0-1160
Distance from spindle axis to column
mm
900
Distance from spindle nose to table
mm
0-1090
X/Y-axis feed speed
mm/min
22.4-560
X/Y-axis rapid feed speed
mm/min
1650
Z-axis feed speed
mm/min
11.2-280
Z-axis rapid feed speed
mm/min
825
Main motor power
kw
7.5
Machine weight
kg
10000
Machine dimensions (L×W×H)
mm
3020x3000x3000
Positive Comments From Customers
Fresadora BM718 High Precision CNC Bed Milling Machine for Professional Machining
Fresadora BM718 High Precision CNC Bed Milling Machine for Professional Machining
Company Introduction
Fresadora BM718 High Precision CNC Bed Milling Machine for Professional Machining
Factory Display：
Fresadora BM718 High Precision CNC Bed Milling Machine for Professional Machining
Text Introduction：
Fresadora BM718 High Precision CNC Bed Milling Machine for Professional Machining
Company Profile：
Timeway Machine Tool Co., Ltd. is a professional machine tool manufacturing enterprises, the main products include lathe, milling machine, grinding machine, etc., and according to customer needs we also can design and manufacture various special purpose machines, to provide relative technology upgrading and transformation services in machine tool field.
Our factory was established in 2014. It has professional technicians, a research and development team, manufactures and sells CNC equipment and provides professional customized services.Our products are widely used in mold processing, 3C products, agricultural machinery, petroleum machinery, auto parts processing, aerospace industry, etc., selling more than 60 countries and regions in domestic and abroad.
