Experience Industrial Machining with BM7110 Bed-Type Milling Machine 3020x3000x3000mm

Product Categories

Zhengzhou Timeway Machine Tool Co., Ltd.

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Experience Industrial Machining with BM7110 Bed-Type Milling Machine 3020x3000x3000mm

Name: Experience Industrial Machining with BM7110 BedType Milling Machine 3020x3000x3000mm
Brand: TIMEWAY
Price: 20 USD

Quality Experience Industrial Machining with BM7110 Bed-Type Milling Machine 3020x3000x3000mm for sale

Table Travel (X) (mm) : 2500

Machining Capacity : Heavy Duty

Table Travel (Y) (mm) : 1020

Table Travel (Z) (mm) : 1090

Spindle Taper : ISO50

Range of Spindle Speed(r.p.m) : 36 - 1340 r.p.m

Place of Origin : Henan, China

Brand Name : TIMEWAY

Model Number : BM7110,BM718

Type : VERTICAL

Spindle Motor Power(kW) : 7.5

Dimension(L*W*H) : 3020x3000x3000mm

Weight (KG) : 10000

Warranty : 1 Year

Key Selling Points : High-accuracy

Marketing Type : Ordinary Product

Machinery Test Report : Provided

Video outgoing-inspection : Provided

Warranty of core components : 1 Year

Name : Milling

Machine Type : Veritcal

Product name : Metal Milling Machine

Keyword : Milling Machine Manual

Function : Machining Metal

Application : Metal Machining

CNC or Not : Normal

Usage : General

Color : Custom-made

Precision : Precision

Number of Axes : 3

Condition : New

Applicable Industries : Machinery Repair Shops, Manufacturing Plant, Home Use, Retail, Energy & Mining

Showroom Location : Romania, South Africa, Japan, Egypt, United Kingdom, United States, France

Core Components : Bearing, Motor

Table Travel (mm) : 700x2800

Year : 223

Packaging Details : Wooden cases(can be fumigated)

Port : China Port

Supply Ability : 150 Set/Sets per Month

Price : $20,000.00/sets 1-2 sets

MOQ : 1 set

Contact Now

Products Description

Experience Industrial Machining with BM7110 Bed-Type Milling Machine 3020x3000x3000mm

SPECIFICATIONS	UNIT	BM718	BM7110
Table size	mm	700x2800	500x2800
Longitudinal travel (X)	mm	2500	2500
Cross travel (Y)	mm	820	1020
Vertical travel (Z)	mm	1090	1090
T slot (No./width/distance)	mm	4/20/100	4/20/100
Loading capacity	kg	5000	5000
Spindle taper		ISO50	ISO50
Spindle speed	rpm	36-1340（12)	36-1340(12)
Distance from spindle axis to table	mm	385-1540/0-1160	385-1540/0-1160
Distance from spindle axis to column	mm	900	900
Distance from spindle nose to table	mm	0-1090	0-1090
X/Y-axis feed speed	mm/min	22.4-560	22.4-560
X/Y-axis rapid feed speed	mm/min	1650	1650
Z-axis feed speed	mm/min	11.2-280	11.2-280
Z-axis rapid feed speed	mm/min	825	825
Main motor power	kw	7.5	7.5
Machine weight	kg	10000	9000
Machine dimensions (L×W×H)	mm	3020x3000x3000	3020x3000x3000

Bed Type Milling Machine High Precision High Quality Detailed Picture

Draw bar
Horizontal mill arbor
Horizontal mill arbor holder
Coolant system
Chip tray
Work lamp
Lubrication system
Tools and Tool box
Operator manual

2/3-axis digital readout
58pcs clamping kit
Machine vise
Spindle protection guard
Table protection guard
Dividing head
Rotary table
Reducing sleeve

Why Choose Us

Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price;
2 . Professional R&D team and 25 years export experience;
3 . Exported more than 60 countries;
4 . CE, ISO Certificates;
5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager);
6 . 12 months quality warranty;
7 . Oversea engineers available for problem resolving;

Q: Do you have QC or any safety standards for your machinery?
A: yes, we have established a highly strict quality control department to guanrantee good quality.

Q: What's the MOQ?
A: 1 set (Only some low cost machines will be more than 1 set )

Q: What about the payment terms?
A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment;
(2) Irrevocable LC at sight;
(3) Western Union, MoneyGram, etc.

Q: How about the warranty?
A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.

Experience Industrial Machining with BM7110 Bed-Type Milling Machine 3020x3000x3000mm Images
