Condition :
New
Spindle Taper :
BT50
No. of Spindles :
3
Type :
VERTICAL
Weight (T) :
10 T
Table Size (mm) :
1360x700
CNC Control System :
GSK, FANUC, MITSUBISHI, KND, Siemens
Number of Axes :
3
Table Travel (X) (mm) :
1300
Table Travel (Y) (mm) :
700
Table Travel (Z) (mm) :
700
Positioning Accuracy (mm) :
±0.01
Repeatability (X/Y/Z) (mm) :
±0.008
Range of Spindle Speed(r.p.m) :
0 - 6000 r.p.m
Spindle Motor Power(kW) :
15/18.5
Max. Table Load(kg) :
1200 kg
Min. Time of Tool Change(s) :
1
Tool Magazine Capacity :
24
Key Selling Points :
Competitive Price
Warranty :
1 Year
Place of Origin :
China
Brand Name :
TIMEWAY
Marketing Type :
Hot Product 2024
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
Machine Type :
CNC Vertical Machine Centers
Guideway type :
Sliding
T-slot (No./width/pitch) :
5-18-152.5mm
Loading capacity :
1200kg
Longitudinal travel (X) :
1300mm
Cross travel (Y) :
700mm
Vertical travel (Z) :
700mm
Spindle taper :
BT-50 (155)
Spindle speed :
6000rpm
Tool magazine capacity :
24 (Disc)T
Applicable Industries :
Hotels, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Restaurant, Printing Shops, Construction works , Energy & Mining
Showroom Location :
Egypt, Canada, United States, Italy, France, Germany, Indonesia, India, Russia, Thailand, South Korea, Chile, Nigeria, Uzbekistan, Japan, Malaysia, Australia
Core Components :
Motor
Price :
$29,800.00/sets 1-2 sets
MOQ :
1 set
