Condition :
New
Spindle Taper :
BT40
No. of Spindles :
1
Type :
VERTICAL
Dimension(L*W*H) :
2800*2350*2800
Weight (T) :
0.5 T
Table Size (mm) :
1000*550mm
CNC Control System :
FANUC, MITSUBISHI, KND, Siemens
Number of Axes :
3
Table Travel (X) (mm) :
800 mm
Table Travel (Y) (mm) :
550 mm
Table Travel (Z) (mm) :
550 mm
Positioning Accuracy (mm) :
0.01 mm
Repeatability (X/Y/Z) (mm) :
0.005
Range of Spindle Speed(r.p.m) :
0 - 6000 r.p.m
Spindle Motor Power(kW) :
7.5
Max. Table Load(kg) :
500 kg
Feed Speed(mm/min) :
0 - 3600 mm/min
Min. Time of Tool Change(s) :
2
Tool Magazine Capacity :
16, 10, 12, 24
Key Selling Points :
Competitive Price
Warranty :
1 Year
Place of Origin :
Henan, China
Brand Name :
Timeway
Voltage :
220V/380V
Marketing Type :
New Product 2020
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
Product name :
3-axis Vertical Cnc Machining Center
Machine Type :
VMC CNC Milling Machine
Application :
Metal Machining
Product type :
Cnc 3 Axis Machine
Processing :
Metal Vertical Milling Machine
Precision :
High Precision Machining Center
Key words :
cnc machine
Function :
Machining Metal
color :
Customers' Request
Key word :
CNC Machining Center Vertical
Applicable Industries :
Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Energy & Mining, Advertising Company
Showroom Location :
None
Core Components :
PLC
Rapid Feed Speed(m/min) :
36
Packaging Details :
Wooden cases(can be fumigated)
Port :
China Port
Supply Ability :
150 Set/Sets per Month
Price :
$38,960.00/sets 1-2 sets
MOQ :
1 set
