1360x700 Table Size VMC1270G Vertical Machining Center for High Accuracy CNC Machining

Condition : New

Spindle Taper : BT-50 (155)

No. of Spindles : 3

Type : VERTICAL

Dimension(L*W*H) : 3820x2600x3100mm

Weight (T) : 9500 KG

Table Size (mm) : 1360x700

Table Travel (X) (mm) : 1200

Table Travel (Y) (mm) : 700

Table Travel (Z) (mm) : 700

Positioning Accuracy (mm) : ±0.003

Repeatability (X/Y/Z) (mm) : ±0.003

Range of Spindle Speed(r.p.m) : 0 - 6000 r.p.m

Max. Table Load(kg) : 1200 kg

Feed Speed(mm/min) : 0 - 2400 mm/min

Min. Time of Tool Change(s) : 2

Tool Magazine Capacity : 24 (Disc)

Key Selling Points : Competitive Price

Warranty : 1 Year

Place of Origin : Henan, China

Brand Name : Timeway

Marketing Type : Hot Product 2024

Machinery Test Report : Provided

Video outgoing-inspection : Provided

Warranty of core components : 1 Year

Machining Capacity : Heavy Duty

Spindle Bore(mm) : Other

Cutting torque : 125 N.m

Rapid Feed Speed(mm/min) : 0 - 2400 mm/min

Product name : CNC Vertical Machining Center

Machine Type : VMC CNC Milling Machine

Application : Metal Machining

Keywords : Vertical Machine Center VMC

Product type : Machining Center Cnc Mill Machine

Color : Custom-made

Worktable size (LxW) : 1360x700mm

Longitudinal travel (X) : 1200mm

Cross travel (Y) : 700mm

Vertical travel (Z) : 700mm

Price : $36,680.00/sets 1-2 sets

MOQ : 1 set

Contact Now

One-Stop Shopping
You can click on the picture to view the products you are interested in
1360x700 Table Size VMC1270G Vertical Machining Center for High Accuracy CNC Machining
1360x700 Table Size VMC1270G Vertical Machining Center for High Accuracy CNC Machining
1360x700 Table Size VMC1270G Vertical Machining Center for High Accuracy CNC Machining
1360x700 Table Size VMC1270G Vertical Machining Center for High Accuracy CNC Machining
1360x700 Table Size VMC1270G Vertical Machining Center for High Accuracy CNC Machining
1360x700 Table Size VMC1270G Vertical Machining Center for High Accuracy CNC Machining
1360x700 Table Size VMC1270G Vertical Machining Center for High Accuracy CNC Machining
1360x700 Table Size VMC1270G Vertical Machining Center for High Accuracy CNC Machining
1360x700 Table Size VMC1270G Vertical Machining Center for High Accuracy CNC Machining
1360x700 Table Size VMC1270G Vertical Machining Center for High Accuracy CNC Machining
1360x700 Table Size VMC1270G Vertical Machining Center for High Accuracy CNC Machining
1360x700 Table Size VMC1270G Vertical Machining Center for High Accuracy CNC Machining
Product Description
Vertical Machining Center VMC1270G
1360x700 Table Size VMC1270G Vertical Machining Center for High Accuracy CNC Machining

MAIN CONFIGURATION & ACCESSORIES:

1. Resin sand casting;
2. X, Y rails adopts imported linear guideway; Z rails are quenching - plastic sliding guide rail pair;
3. X, Y, Z rails adopt stainless steel telescopic cover;
4. Standard with belt driven spindle, optional for direct driven spindle;
5. Taiwan production pneumatic cylinder;
6. Taiwan ATC, carousel type and disc type are available as option;
7. Imported bearings for leadscrews;
8. Import coupling;
9. Headstock balancing system have heavy casting or nitrogen balance system as option;
10. Full enclosure;
11. Rigid tapping;
12. Spindle center air blast;
13. Work lamp;
14. Pilot lamp;
15. USB and LAN interface;
16. Manual pulse generator (MPG);
17. Centralized automatic lubrication system.
18. Cooling system.
19. Heat exchanger for electrical cabinet ;
20. Leveling blocks & bolts;
21. Toolbox and tools;
22. CNC controller: KND,GSK, HNC (China); SIEMENS, FANUC, MITSUBISHI, FAGOR, etc.

OPTIONAL CONFIGURATION & ACCESSORIES:

1. The 4th axis wiring;
2. NC rotary table;
3. Direct driven spindle (Speed: 10000rpm, 12000rpm, 15000rpm);
4. Circular Coolant Nozzle;
5. Coolant through spindle (CTS);
6. Spindle oil cooler;
7. Air conditioner (A/C) for electrical cabinet;
8. Auto. Tool length measurement system;
9. Auto. Workpiece measurement systems;
10. Screw type chip conveyor;
11. Chain type chip conveyor;
12. High pressure water flush system;
13. Safety door;
14. Oil skimmer.
Specification
Specification
Unit
VMC1270G
Worktable size (LxW)
mm
1360×700
T-slot (No./width/pitch)
mm
5-18-152.5
Loading capacity
kg
1200
Longitudinal travel (X)
mm
1200
Cross travel (Y)
mm
700
Vertical travel (Z)
mm
700
Distance from spindle nose to table
mm
140-840
Distance from spindle center to column
mm
816
Spindle taper
-
BT-50 (155)
Spindle speed
rpm
6000
X/Y/Z-axis rapid feed speed
m/min
24/24/24
X/Y/Z-axis servo motor (FANUC)
-
β22/β22/β30
X/Y/Z-axis positioning accuracy
mm
±0.003/300
X/Y/Z-axis repeat positioning accuracy
mm
±0.003/300
Main motor power
kw
15/18.5
Air pressure source
kg/cm2
6-8
Power capacity
Kva
30
Tool magazine capacity
T
24 (Disc)
Guideway type
-
Linear
Machine weight
kg
9500
Machine dimensions (LxWxH)
mm
3820×2600×3100
Client feedback
Our Services
1. Free replacing parts available in the warranty period. Cost price replacing parts available beyond the warranty period. 2. Quick action and reply for the technical questions at any time in the whole life of the machine. 3. Overseas after service center available in some region. 4. Engineer overseas service available on the requirement of customer(relative cost born by customer).
Company Introduction
1360x700 Table Size VMC1270G Vertical Machining Center for High Accuracy CNC Machining
Factory Display：
1360x700 Table Size VMC1270G Vertical Machining Center for High Accuracy CNC Machining
Factory Profile：
Our factory was established in 2014. It has professional technicians, a research and development team, manufactures and sells CNC equipment and provides professional customized services.Our products are widely used in mold processing, 3C products, agricultural machinery, petroleum machinery, auto parts processing, aerospace industry, etc., selling more than 60 countries and regions in domestic and abroad.
Text Introduction：
1360x700 Table Size VMC1270G Vertical Machining Center for High Accuracy CNC Machining
Company Profile：
Timeway Machine Tool Co., Ltd. is a professional machine tool manufacturing enterprises, the main products include lathe, milling machine, grinding machine, etc., and according to customer needs we also can design and manufacture various special purpose machines, to provide relative technology upgrading and transformation services in machine tool field.
1360x700 Table Size VMC1270G Vertical Machining Center for High Accuracy CNC Machining
Customer Visited：
So far, we have received many customers from abroad, and they are all very satisfied with our company and products
1360x700 Table Size VMC1270G Vertical Machining Center for High Accuracy CNC Machining
Exhibitions：
Since the establishment of the Ministry of Foreign Trade, we have participated in various domestic and international exhibitions such as the Autumn Canton Fair, Beijing Exhibition, Shanghai Exhibition, Moscow, Ethiopia, and Russia, and have maintained long-term friendly cooperative relations with exhibition customers.
FAQ
Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price; 2 . Professional R&D team and 25 years export experience; 3 . Exported more than 60 countries; 4 . CE, ISO Certificates; 5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager); 6 . 12 months quality warranty; 7 . Oversea engineers available for problem resolving; Q: Do you have QC or any safety standards for your machinery? A: yes, we have established a highly strict quality control department to guanrantee good quality. Q: What's the MOQ? A: 1 set (Only some low cost machines will be more than 1 set ) Q: What about the payment terms? A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment; (2) Irrevocable LC at sight; (3) Western Union, MoneyGram, etc. Q: How about the warranty? A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
