Multifunctional Horizontal Machine Center with and X/Y/Z-Axis Feed Speed 1-5000mm/min

Name: Multifunctional Horizontal Machine Center with and XYZAxis Feed Speed 15000mmmin
Brand: timac
Price: 80 USD

Quality Multifunctional Horizontal Machine Center with and X/Y/Z-Axis Feed Speed 1-5000mm/min for sale

Condition : New

Spindle Taper : BT40

No. of Spindles : Single

Type : Horizontal

Dimension(L*W*H) : 3500x2900x3280

Weight (T) : 7 T

Table Size (mm) : 500x500

CNC Control System : GSK, FANUC, Siemens

Number of Axes : 6

Table Travel (X) (mm) : 1050

Table Travel (Y) (mm) : 800

Table Travel (Z) (mm) : 700

Positioning Accuracy (mm) : ±0.001

Repeatability (X/Y/Z) (mm) : ±0.001

Range of Spindle Speed(r.p.m) : 1 r.p.m

Spindle Motor Power(kW) : 50

Max. Table Load(kg) : 800 kg

Min. Time of Tool Change(s) : 6

Tool Magazine Capacity : 12

Key Selling Points : Multifunctional

Warranty : 1 Year

Place of Origin : China

Brand Name : timac

Voltage : 220-380v

Marketing Type : Ordinary Product

Machinery Test Report : Provided

Video outgoing-inspection : Provided

Warranty of core components : 1 Year

Table size : 630x630mm

Number of table : 1pcs

Table indexing : 1°

T-slots : 6x18x100mm

Loading capacity : 800

X/Y/Z-axis travel : 1000/750/600mm

X/Y/Z-axis feed speed : 1-5000mm/min

Positioning accuracy : 0.01

Machine weight : 8000kg

Repeat positioning accuracy : 0.005mm

Applicable Industries : Machinery Repair Shops

Showroom Location : Egypt, Turkey, France, Viet Nam, Philippines, UAE, Algeria, Tajikistan

Core Components : Bearing

Packaging Details : Woode case/Pallet

Port : China port

Supply Ability : 150 Set/Sets per Month

Price : $80,000.00/sets 1-2 sets

MOQ : 1 set

Contact Now

Products Description

Multifunctional Horizontal Machine Center with and X/Y/Z-Axis Feed Speed 1-5000mm/min

Specification	Unit	HMC630	HMC800
Table size	mm	630x630	800x800
Number of table	pcs	1	1
Table indexing	°	1	1
T-slots	mm	6x18x100	5x20x160
Loading capacity	kg	800	2500
Distance from spindle center to table surface	mm	25-775	0-1000
Distance from spindle nose to table center	mm	120-720	180-1180
X/Y/Z-axis travel	mm	1000/750/600	1600/1000/1000
X/Y/Z-axis feed speed	mm/min	1-5000	1-5000
X/Y/Z-axis rapid feed speed	m/min
Spindle taper	-	BT40	BT50
Spindle speed	rpm	6000	6000
Main motor	kw	7.5/11	15/18.5
X/Y/Z-axis motor torque	N.m	14/16/16	30/30/30
Tool magazine	tools	disc-type	chain-type
CNC system	-	GSK/FANUC
Positioning accuracy	mm	0.01	0.01
Repeat positioning accuracy	mm	0.005	0.005
Machine weight	kg	8000	15000
Size of tool shank	mm	25
Diameter of Tailstock quill	mm	85
Travel of tailstock quill	mm	150
Taper Hole of tailstock quill	Morse	Morse No. 5
Workpiece accuracy		IT6IT7
Surface roughness	µm	Ra1.6
Main power	kW	7.5
Lathe weight	kg	2600/2900/3200/3600/4000
Overall dimensions(Length×width×height)	mm	2380/2610/2860/3430/3910×1340×1750

Why Choose Us

Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price;
2 . Professional R&D team and 25 years export experience;
3 . Exported more than 60 countries;
4 . CE, ISO Certificates;
5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager);
6 . 12 months quality warranty;
7 . Oversea engineers available for problem resolving;

Q: Do you have QC or any safety standards for your machinery?
A: yes, we have established a highly strict quality control department to guanrantee good quality.

Q: What's the MOQ?
A: 1 set (Only some low cost machines will be more than 1 set )

Q: What about the payment terms?
A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment;
(2) Irrevocable LC at sight;
(3) Western Union, MoneyGram, etc.

Q: How about the warranty?
A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
