CNC Milling Machine TIMEWAY 630mm Horizontal Machining Center with FANUC Control System

Name: CNC Milling Machine TIMEWAY 630mm Horizontal Machining Center with FANUC Control System
Brand: Timeway/TIMAC
Price: 75 USD

Quality CNC Milling Machine TIMEWAY 630mm Horizontal Machining Center with FANUC Control System for sale

Type : Horizontal

Range of Spindle Speed(r.p.m) : 0 - 6000

Number of Axes : 4

No. of Spindles : Single

Machining Capacity : Medium Duty

Spindle Taper : BT50

Table Travel (X) (mm) : 1050

Table Travel (Y) (mm) : 800

Table Travel (Z) (mm) : 700

Positioning Accuracy (mm) : 0.01

Repeatability (X/Y/Z) (mm) : 0.006

Place of Origin : Henan, China

Brand Name : Timeway/TIMAC

Model Number : HMC630

Dimension(L*W*H) : 4285x3120x3280mm

CNC Control System : FANUC

Key Selling Points : High-accuracy

Weight (KG) : 8800

Spindle Motor Power(kW) : 15

Warranty : 1 Year

Max. Table Load(kg) : 800 kg

Marketing Type : Hot Product 2022

Machinery Test Report : Provided

Video outgoing-inspection : Provided

Warranty of core components : 1 Year

Name : Horizontal Machining Center

CNC or Not : CNC Machining Center

Table size : 630*630mm

Model : HMC630

Color : Cusomer Request

Spindle Speed : 6000rpm

X/Y/Z-Axis travel : 1050/800/700mm

CNC Controller : FANUC-0i MF

T Slot : 6/18/100

Machine weight : 8800kg

Condition : New

Applicable Industries : Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Construction works , Advertising Company

Showroom Location : Egypt, United States, Philippines, Pakistan, Thailand, Chile, Romania, Kyrgyzstan

Core Components : Bearing, Pump, Gear, Gearbox

Packaging Details : Wooden cases(can be fumigated)

Port : China Port

Supply Ability : 150 Set/Sets per Month

Price : $75,000.00/sets 1-2 sets

MOQ : 1 set

Contact Now

Product Description

Horizontal Machining Center

Features:

==The HMC series horizontal machining center is a CNC horizontal machining center controlled by CNC (computer numerical control device) and performing cutting processing. It can perform drilling, tapping and milling; it can solve the processing of complex,precise, small batch, and multi-variety parts.
==Standard equipped with B axis (NC rotary table) dividing processing requirement.
==The structure of HMC horizontal machining center can divide into three kinds: Positive T-type; Inverted T-type; Cross-type.Realize various processing requirements of the different size and different shape workpieces.

Specification

Specification	Unit	HMC630
Machine structure	/	Positive T-type
X-axis trave	mm	1050
Y-axis travel	mm	800
Z-axis travel	mm	700
Table size	mm	630×630
Table number	pcs	1
Table indexing	°	1°×360
T-slots (No./width/pitch)	/	6/18/100
Table rotation speed	rpm	11.1
Loading capacity	kg	800
Locking force (35kg / cm2)	kg/m	5000
Distance spindle center to table	mm	150-750
Distance spindle nose to table center	mm	150-700
Spindle taper	/	BT-50
Spindle speed	rpm	6000
Main motor power	kw	15/18.5
X/Y/Z-axis rapid feed speed	m//min	30/15/30
X/Y/Z-axis guideway type	-	X/Z: Linear/Y: sliding
X/Y/Z-axis positioning accuracy	mm	0.01
X/Y/Z-axis repeat positioning accuracy	mm	0.006
B-axis positioning accuracy	"	10"
ATC style	/	Disc
ATC capacity	tools	24
Tool change time (tool to tool)	sec	7
Max. tool weight	kg	8
Max. tool diameter	mm	Φ78/Φ125
Max. tool length	mm	300
Power capacity	kva	50
Air pressure	kg/cm2	8
Machine weight	kg	8800
Overall dimension (LxWxH)	mm	4285×3120×3280

Accessories

Standard accessories:

√ FANUC 0i MF CNC system

√ X/Z: Linear guide rails, Y: Sliding guide rail
√ Taiwan BT50 spindle, 6000rpm
√ Taiwan NC rotary table (B-axis)
√ Taiwan disc-type ATC with 24tools
√ Full enclosure
√ Manual pulse generator (MPG)
√ USB & LAN interface
√ Work lamp
√ Pilot lamp
√ Cooling system
√ Centralized automatic lubrication system
√ Spindle air blast
√ Air gun
√ Milling arbor & chuck
√ Heat exchanger for electric cabinet
√ Tools & tool-box
√ Leveling wedge & bolts
√ Operation manual (English)

Optional accessories:

_ MITSUBISHI/SIEMENS/FAGOR/GSK/HNC/KND
_ Direct driven spindle (10000, 12000, 15000rpm)
_ Circular coolant nozzle
_ Coolant through spindle (CTS)
_ Spindle oil cooler
_ Air conditioner
_ Chain-type chip conveyor
_ Water gun
_ Safety door
_ Tool measurement system
_ Workpiece measurement system

Company Profile

Timeway Machine Tool Co., Ltd. is a professional machine tool manufacturing enterprises, the main products include lathe, milling machine, grinding machine, etc., and according to customer needs we also can design and manufacture various special purpose machines, to provide relative technology upgrading and transformation services in machine tool field.

Our company has advanced production testing equipment, first-class R & D, production, sales and service teams, and behave the own production and acceptance standard higher than the national standard to ensure that each machine delivered by us can make customer satisfaction and help customer create the greatest benefits.

Client feedback

Adhering to the "quality products, first-class service, sustainable development" concept, adhere to the "low-key life,high-profile work" spirit of enterprise, look forward to sincere cooperation and work together with the friends from domestic and abroad to create a better future for all.

FAQ

Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price;
2 . Professional R&D team and 25 years export experience;
3 . Exported more than 60 countries;
4 . CE, ISO Certificates;
5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager);
6 . 12 months quality warranty;
7 . Oversea engineers available for problem resolving;

Q: Do you have QC or any safety standards for your machinery?
A: yes, we have established a highly strict quality control department to guanrantee good quality.

Q: What's the MOQ?
A: 1 set (Only some low cost machines will be more than 1 set )

Q: What about the payment terms?
A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment;
(2) Irrevocable LC at sight;
(3) Western Union, MoneyGram, etc.

Q: How about the warranty?
A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
