Large-Sized CNC Horizontal Lathe Machine Ideal for Heavy Duty and Precision Work

Product Categories
Zhengzhou Timeway Machine Tool Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Large-Sized CNC Horizontal Lathe Machine Ideal for Heavy Duty and Precision Work

Max. Length of Workpiece (mm) : 1000

Range of Spindle Speed(r.p.m) : 5 - 320 r.p.m

Machining Capacity : Heavy Duty

Width of bed (mm) : 750

Type : Horizontal

Spindle Motor Power(kW) : 30

Place of Origin : Henan, China

Brand Name : Timeway

Model Number : AK-1600B

Dimension(L*W*H) : 4300*2780*2600

Weight (KG) : 9800 KG

Warranty : 1 Year

Key Selling Points : Competitive Price

Marketing Type : New Product 2020

Machinery Test Report : Provided

Video outgoing-inspection : Provided

Warranty of core components : 1 Year

Distance between centers : 1000mm/1500mm/2000mm/3000mm

Loading capacity : 6000kg/8000kg

Spindle bole : 130mm

Machine Type : Horizontal CNC Lathe

Name : Cnc Lathe Machine

Keyword : Turning Machine

CNC or Not : CNC

Color : Customised

Precision : High Precision Machine

Max. swing over bed : 1640mm

Condition : New

Spindle Bore(mm) : 130

Applicable Industries : Machinery Repair Shops, Manufacturing Plant

Showroom Location : Turkey, United Kingdom, United States, Italy, France, Germany, Peru, Mexico

Core Components : Bearing, Pump, PLC

Max. Turned Length (mm) : 730 mm

Year : 2020

Price : $100,000.00/sets 1-2 sets

MOQ : 1 set

Contact Now

Product Description
Large-Sized CNC Horizontal Lathe Machine Ideal for Heavy Duty and Precision Work
Features:
1.This bed is the box-shaped structure, adopts high standard cast iron one molding casting, after the second aging treatment, with stable performance; guide-way width, good rigidity, anti-vibration ability; processed by medium-frequency hardening and machined by the imported guideway grinding machine, to ensure a long service life, high precision and good maintainability.

2.The spindle bore diameter is 100mm, with the heavy-duty bearings for three-point support, rotating stability, automatic forced circulation lubrication, making the transmission system is flexible and cooling effectively.

3.This series of lathe machine is used widely, flexible operation, suitable for processing all kinds of complex shapes of shafts, pipes, disk parts, such as turning inner and outer cylinder surface, conical surface, circular surface, end face, grooving chamfer, threading, especially for muti-species, small batch of turns processing, process adaptability, high processing efficiency, low scrap rate, good product consistency, easy programming, simple operation, reducing the technical requirements of workers, it is the ideal medium mechanical processing.
Detailed Images
Large-Sized CNC Horizontal Lathe Machine Ideal for Heavy Duty and Precision Work
Large-Sized CNC Horizontal Lathe Machine Ideal for Heavy Duty and Precision Work
Specification
SPECIFICATION
UNIT
AK-1600B
Cross travel (X)
mm
630
Dimension(L*W*H)
mm
4300*2780*2600
Weight
kg
9800
Max. swing over bed
mm
1640
Max. swing over cross slide
mm
1250
Distance between centers
mm
1000
Max. turning length
mm
730
Bed width
mm
755
Loading capacity
kg
6000
Spindle nose
mm
A2-15
Spindle bore
mm
130
Main motor power
kw
30
Packing & Delivery
Large-Sized CNC Horizontal Lathe Machine Ideal for Heavy Duty and Precision Work
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Company Profile
Large-Sized CNC Horizontal Lathe Machine Ideal for Heavy Duty and Precision Work
Timeway Machine Tool Co., Ltd. is a professional machine tool manufacturing enterprises, the main products include lathe, milling machine, grinding machine, etc., and according to customer needs we also can design and manufacture various special purpose machines, to provide relative technology upgrading and transformation services in machine tool field.

Our factory was established in 2014. It has professional technicians, a research and development team, manufactures and sells CNC equipment and provides professional customized services.Our products are widely used in mold processing, 3C products, agricultural machinery, petroleum machinery, auto parts processing, aerospace industry, etc., selling more than 60 countries and regions in domestic and abroad.
Large-Sized CNC Horizontal Lathe Machine Ideal for Heavy Duty and Precision Work
Large-Sized CNC Horizontal Lathe Machine Ideal for Heavy Duty and Precision Work
FAQ
Q: Why choose TIMEWAY MACHINE?
A:1 . High quality with competitive price;
2 . Professional R&D team and 25 years export experience;
3 . Exported more than 60 countries;
4 . CE, ISO Certificates;
5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager);
6 . 12 months quality warranty;
7 . Oversea engineers available for problem resolving;

Q: Do you have QC or any safety standards for your machinery?
A: yes, we have established a highly strict quality control department to guanrantee good quality.

Q: What's the MOQ?
A: 1 set (Only some low cost machines will be more than 1 set )

Q: What about the payment terms?
A:(1)T/T with 30% advanced payment, and 70% balance payment to be paid before shipment;
(2) Irrevocable LC at sight;
(3) Western Union, MoneyGram, etc.

Q: How about the warranty?
A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
