16000kg Max. Workpiece Weight CNC Vertical Lathe Machine with High Speed Round Table

Name: 16000kg Max Workpiece Weight CNC Vertical Lathe Machine with High Speed Round Table
Brand: Timeway
Price: 180 USD

Quality 16000kg Max. Workpiece Weight CNC Vertical Lathe Machine with High Speed Round Table for sale

Type : VERTICAL

Max. Length of Workpiece (mm) : 2000/2500

Machining Capacity : Heavy Duty

Max. Weight of Workpiece(kg) : 16000

Width of bed (mm) : 1500 mm

Spindle Motor Power(kW) : 70.6

No. of Spindles : Single

Number of Axes : 2

Travel (X Axis)(mm) : 1450 mm

Travel (Z Axis)(mm) : 1250 mm

Place of Origin : Henan, China

Dimension(L*W*H) : 8470*5340*6450

Brand Name : Timeway

Model Number : VDK2500E

Voltage : 220v/380v

Tool Post Stations : 4

Weight (KG) : 41000

Warranty : 1 Year

Key Selling Points : Easy to Operate

Machinery Test Report : Provided

Video outgoing-inspection : Provided

Warranty of core components : 1 Year

Machine Type : Vertical CNC Lathe

CNC or Not : CNC

Max. height of workpiece : 2000/2500

Key word : CNC Lathe Machine

Product type : CNC Lathe Machine

Color : Customer Optional

Precision : High Precision Machine

Control system : SIEMENS GSK FANUC (optional)

Model : VDK2500E

Max.swing over bed : 2500

Condition : New

Showroom Location : Italy, France, Germany, Russia, Morocco

Core Components : Bearing, Motor, PLC, Engine

Year : custom made

Max. Spindle Speed (r.p.m) : 63 r.p.m

Spindle Bore(mm) : 200

Max. Turned Length (mm) : 2500

Applicable Industries : Machinery Repair Shops, Manufacturing Plant, Mould, mental process

Marketing Type : Hot Product

Packaging Details : Wooden cases(can be fumigated)

Port : China Port

Supply Ability : 150 Set/Sets per Month

Price : $180,000.00/sets 1-2 sets

MOQ : 1 set

Contact Now

Product Description

16000kg Max. Workpiece Weight CNC Vertical Lathe Machine with High Speed Round Table

1. The series CNC single column vertical lathe is designed by absorbing modern advanced design and manufacturing techniques and using CAD optimization design method, using the latest design concept and equipping with domestic and foreign advanced features.

2. The machine is suitable for high speed steel and carbide cutting tools, processing workpieces of all ferrous and non-ferrous metals and some nonmetal materials.

Detail Images

Specification

SPECIFICATIONS	UNIT	VDK2500E
Max.turning diameter	mm	Φ2500
Max. height of workpiece	mm	2000/2500
Max. weight of workpiece	kg	16000
Table diameter	mm	Φ2250
Max. turning force of vertical tool post	KN	35
Max. torque of table	KN.m	63
Machine dimensions (LxWxH)	mm	8470×5340×6450
Machine weight	kg	41000

Packing & Delivery

Company Profile

Our products are widely used in mold processing, 3C products, agricultural machinery, petroleum machinery, auto parts processing, aerospace industry, etc., selling more than 60 countries and regions in domestic and abroad.

FAQ

1. who are we?
We are based in Henan, China, start from 2010,sell to South America(20.00%),Africa(15.00%),Eastern Europe(15.00%),South Asia(10.00%),North America(10.00%),Oceania(10.00%),Western Europe(10.00%),Southeast Asia(10.00%). There are total about 11-50 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Lathe, CNC Lathe, CNC Milling Machine, Machining Center, Grinding Machine

4. why should you buy from us not from other suppliers?
Our factory have more than 50years experience of researching & producing lathe and heavy duty lathe, both conventional and CNC types, normal use and special use, etc.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,Western Union,Cash;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian

16000kg Max. Workpiece Weight CNC Vertical Lathe Machine with High Speed Round Table Images
