Medium Duty TORNOS Series Universal Precision Gap Bed Lathe Machine Weight KG 2300 KG

Name: Medium Duty TORNOS Series Universal Precision Gap Bed Lathe Machine Weight KG 2300 KG
Brand: TIMAC
Price: 5 USD

Quality Medium Duty TORNOS Series Universal Precision Gap Bed Lathe Machine Weight KG 2300 KG for sale

Max. Length of Workpiece (mm) : 1500

Range of Spindle Speed(r.p.m) : 36 - 1600 r.p.m

Machining Capacity : Medium Duty

Type : Horizontal

Spindle Motor Power(kW) : 7.5

Place of Origin : Henan, China

Brand Name : TIMAC

Model Number : CS-6240B CS-6250B CS-6266B CS6280B CS6250C

Voltage : As Customers' Request

Dimension(L*W*H) : 3132x975x1230mm

Weight (KG) : 2300 KG

Warranty : 1 Year

Key Selling Points : High-accuracy

Marketing Type : Other

Machinery Test Report : Provided

Video outgoing-inspection : Provided

Warranty of core components : 1 Year

CNC or Not : Normal

Automatic Grade : Manual

After-sales Service Provided : Online support

Universal Lathe : Precision Gap Bed Lathe

Max. Swing Diameter over bed : 500mm

Power : 7.5KW

Certification : ISO, CE Standard

Max. workpiece length : 1500mm

Spindle bore diameter : 82mm

Warranty period : 1 year

Condition : New

Spindle Bore(mm) : 82

Showroom Location : United Kingdom, United States, Italy, France, Germany, Brazil, Peru, Pakistan, India, Russia, Argentina, Chile, UAE, South Africa, Kazakhstan, Nigeria, Malaysia, Australia

Max. Turned Length (mm) : 1500 mm

Applicable Industries : Building Material Shops, Manufacturing Plant, Retail, Construction works , Other

Core Components : Bearing, Gear, Motor, Gearbox, Other

Packaging Details : wooden case or plywood case

Supply Ability : 300 Set/Sets per Month

Price : $5,999.00/sets >=1 sets

MOQ : 1 set

Contact Now

Products Description

Features:

1. Can perform internal and external turning, taper turning, end facing, and other rotary parts turning;

2. Threading Inch, Metric, Module and D.P;

3. Perform drilling, boring and groove broaching;

4. Machine all kinds of flat stocks and those in irregular shapes;

5. Respectively with through-hole spindle bore, that can hold barstocks in larger diameter;

6. Both Inch and Metric system are used on these series lathes, it's easy for people from different measuring systems countries;

7. There are hand brake and foot brake for users to choose.

Medium Duty TORNOS Series Universal Precision Gap Bed Lathe Machine Weight KG 2300 KG

· 3-jaw chuck
· Steady rest (over 2M length)
· Follow rest (over 2M length)
· Manual moving tailstock
· Dead center of tailstock
· 4-station tool post
· Cooling system
· Work lamp
· Tools & tool-box
· Leveling wedge and bolts
· Operation manual (English)

· 4-jaw independent chuck
· Face plate
· 2 or 3-axis digital indicator
· Chuck guard

· Too-post guard

· Rear splash guard
· Quick changing tool post

Specification

Unit

CS6240B

CS6250B

CS6266B

CS6280B

CS6250C

CS6266C

CS6280C

Max. swing dia. over bed

Φ400

Φ500

Φ660

Φ800

Φ500

Φ660

Φ800

Max. swing dia.in gap

Φ630

Φ710

Φ870

Φ1000

Φ710

Φ870

Φ1000

Max. swing dia. over slides

Φ220

Φ300

Φ420

Φ560

Φ300

Φ420

Φ560

Max. workpiece length

1000/ 1500/ 2000/ 3000

2000/ 3000

1000/ 1500/ 2000/ 3000

2000/ 3000

Spindle bore diameter

Φ52

Φ82

Φ52

Φ105

Φ52

Type of spindle nose

6240B: ISO 702/III NO.6 bayonet lock;

others: ISO 702/II NO.8 com-lock type

Spindle speed

rpm

24 steps 9-1600

24 steps 8-1400

12 steps 36-1600

12 steps 30-1400

Diameter of quill

Φ75

Φ90

Φ75

Φ90

Max. travel of quill

150

Taper of quill (Morse)

Tool O.D. size

25x25

Max. X travel

145

Max. Z travel

320

310

320

X feed range

mm/r

93 kinds 0.028-6.43

65 kinds 0.063-2.52

Z feed range

mm/r

93 kinds 0.012-2.73

65 kinds 0.027-1.07

Metric threads

48 kinds 0.5-224

22 kinds 1-14

Inch threads

t.p.i

48 kinds 72-1/4

25 kinds 28-2

Module threads

nmm

42 kinds 0.5-112

18 kinds 0.5-7

Diametric pitch threads

t.p.i.

42 kinds 56-1/4

24 kinds 56-4

Spindle motor power

7.5

Cooling pump motor power

0.06

Length

2632/ 3132/ 3632/ 4632

3365/ 4365

2632/ 3132/ 3632/ 4632

3365/ 4365

Width

975

1050

1340

975

1340

Height

1230

1350

1430

1270

1450

1490

Weight

2050/ 2250/ 2450/ 2850

2100/ 2300/ 2500/ 2900

2400/ 2600/ 2800/ 3000

3300/ 3700

2100/ 2300/ 2500/ 2900

2200/ 2400/ 2600/ 3000

3000/ 3200
