22kW Spindle Motor High Precision Large Type Horizontal Lathe for Heavy Components

Name: 22kW Spindle Motor High Precision Large Type Horizontal Lathe for Heavy Components
Brand: Timeway
Price: 18 USD

Quality 22kW Spindle Motor High Precision Large Type Horizontal Lathe for Heavy Components for sale

Max. Length of Workpiece (mm) : 3000

Range of Spindle Speed(r.p.m) : 3.15 - 315 r.p.m

Machining Capacity : Heavy Duty

Width of bed (mm) : 187

Type : Horizontal

Spindle Motor Power(kW) : 22

Place of Origin : Henan, China

Brand Name : Timeway

Model Number : AL-1400C

Voltage : 220V/380V/400V/415V

Dimension(L*W*H) : 7020*1995*2075

Weight (KG) : 1900 KG

Warranty : 1 Year

Key Selling Points : Competitive Price

Marketing Type : New Product 2021

Machinery Test Report : Provided

Video outgoing-inspection : Provided

Warranty of core components : 1 Year

Name : Manual Lathe Machine

Machine Type : Horizontal Metal Turning Lathe Machine

Product Name : Manual Metal Lathe Machine

After-sales Service Provided : Online Support

Keyword : Universal Metal Lathe

Color : Customrized

Precision : High Precision

Function : Machining Metal

Application : Precision Metal Turning

Processing : Metal Workpiece

Condition : New

Spindle Bore(mm) : 38

Showroom Location : United States, Germany, Philippines, Saudi Arabia, Pakistan, Russia, Thailand, Kenya, Argentina, South Korea, Chile, UAE, Colombia, Algeria, Bangladesh, Japan

Core Components : Bearing, Gear, Motor, Gearbox, Engine

Max. Turned Length (mm) : 2800 mm

Year : 2021

Applicable Industries : Machinery Repair Shops, Manufacturing Plant, Retail, Construction works , Energy & Mining, Other

Packaging Details : Wooden cases(can be fumigated)

Port : China Port

Supply Ability : 150 Set/Sets per Month

Price : $18,000.00/sets 1-2 sets

MOQ : 1 set

Contact Now

Product Description

Heavy Duty Horizontal Lathe

22kW Spindle Motor High Precision Large Type Horizontal Lathe for Heavy Components

1.This series heavy duty lathe adopts 970mm wide induction hardened and ground bed guide
ways, so of excellent stability, high rigidity, and with maximum bearings of 10 tons between centers.
2.The main spindle is of precision roller bearings 3-point supporting structure. Saddle guide ways with Teflon belt coated.
Rotating tailstock quill structure to minimize friction and heat generation.
3.These machines are suitable for various turning works, such as turning of external and internal cylindrical surfaces, end faces, and turning of metric or inch threads and diametrical pitch threads, etc.
4.Motorized short taper turning could be done by the top slide independently, and long taper's motorized turning could be done by top slide combined with longitudinal feed. Further more, these machines can also carry out drilling, trepanning and boring processes, etc.

Specification

Specification					Al-1250C	AL-1400C	AL-1600C	AL-1800C
Capacity	Swing over bed			1250	1400	1600	1800
		Swing over cross slide			865	1010	1210	1280
		Max.length of workpiece			3000/4000/5000/6000/8000/10000/12000/14000/16000/18000
		Max.length of turning			2800/3800/4800/5800/7800/9800/11800/13800/15800/17800
		Width of bed			970
		Max.torque of spindle			12590
		Max.cutting force			45000
		Max.force of logitudinal			18000
		Max.weight of workpiece			10000
Spindle	Dia.of spindle bore			130
		Taper of spindle			metric140
		No.of forward turning			21 kinds
		No.of reverse turning			12 kinds
		Spindle speed	Forward	3.15-315
		Spindle speed		Reverse	3.5-291
Feed motion	No.of feeds per revolution			(Longitudinal/tranverse)56/56
		Feed per revolution	Longutudinal	0.1-12(0.004"-0.473"
				Tranverse	0.05-6(0.002"-0.236")
				Upper tool-post	0.025-3(0.001"-0.118")
		No.and range of metric thread			44kinds:1-120
		No.and range of inch thread			31kinds:28-1/4
		No.and range of module thread			45kinds:0.5-60
		No.and range of diametrical thread			38kinds:1/2-56
Tool post	Size of tool shank			45×45
		swing range of tool post			±90º
		Max.travel of cross slide			650
		Max.travel of top slide			300
		Rapid of tool post			Longitudianl:3740 Tranverse:1870 Top slide:935
Tailstock	Dia.of tailstock quill			220
		Travel of tailstock quill			300
		Taper hole of tailstock quill			Morse No.6#
Others	Main motor power			22
		Power of tool post rapid move motor			1.5
		Power of cooling pump			0.15
Overall dimension	Length			6020/7020/8020/9020/11020/13020/15020/17020/19020/21020
		Width			1995
		Height			2175	2325	2525	2725

Detailed Images
