500mm Travel Vertical Boring Milling Machine for Precise Drilling

Table Size (mm) : 500x1250

Table Travel (X) (mm) : 1500 mm

Table Travel (Y) (mm) : 200 mm

Table Travel (Z) (mm) : 350 mm

Number of Axes : 2

Travel (W-axis) (mm) : 500 mm

Video outgoing-inspection : Provided

Machinery Test Report : Provided

Marketing Type : Ordinary Product

Warranty of core components : 1 Year

Core Components : Engine, Motor

Range of Spindle Speed(r.p.m) : 120 r.p.m

Type : VERTICAL

Condition : New

CNC or Not : Normal

Place of Origin : China

Voltage : 220v/380v

Weight (T) : 3.8 T

Warranty : 1 Year

Key Selling Points : Competitive Price

Applicable Industries : Manufacturing Plant, Machinery Repair Shops

Showroom Location : Mexico, Russia, Spain, Thailand, Chile, Algeria, Romania

Product name : Vertical Boring Milling Machine

Style : Fashion

Max. drilling & reaming diameter : 30mm

Packaging Details : WOODEN CASE/PLYWOOD CASE

Port : CHINA PORT

Supply Ability : 500 Set/Sets per Month

Price : $27,500.00/sets 1-2 sets

MOQ : 1 set

Contact Now

Vertical Boring Milling Machine

500mm Travel Vertical Boring Milling Machine for Precise Drilling

This serial model of Vertical Boring Milling Machine can be widely used in boring automobile engine cylinders, cylinder sleeves of diesel engines and compressors, as well as various high precision holes boring, surface milling of other workpieces.

Model		TX170A	TX200A	TX250A
Max. boring diameter		Φ170 mm	Φ200 mm	Φ250 mm
Max. boring depth		400 mm	500 mm	500 mm
Max. milling area		400x1000 mm
Max. drilling & reaming diameter		Φ30 mm
Spindle speed		120-860 r/min
Feeding of the spindle		14-900 mm/min
Rapid moving speed of the spindle		1000 mm/min
Spindle travel		700 mm
Distance between spindle end face and table		0-700 mm
Distance between spindle axis and carriage vertical plane		375 mm
Feed of work table longitudinal		32-1350 mm/min
Rapid moving speed of the table longitudinal travel		32-1350 mm/min
Max longitudinal travel of working table		1500 mm
Max cross travel of the working table		200 mm
Working table size (W×L)		500×1250 mm	500×1500 mm
Main motor		5.5 Kw
Processing roughness	Boring	Ra 2.5
	Milling	Ra 3.2
Overall dimensions (L×W×H)		2600×1630×2300 mm
Packing dimensions (L×W×H)		2250×1900×2280 mm
N.W./G.W.		3300/3600 kg	3500/3800 kg

Packaging & Shipping

500mm Travel Vertical Boring Milling Machine for Precise Drilling

Company Introduction

500mm Travel Vertical Boring Milling Machine for Precise Drilling

Export Cases

500mm Travel Vertical Boring Milling Machine for Precise Drilling

Exhibitions

500mm Travel Vertical Boring Milling Machine for Precise Drilling

Customers Visited

500mm Travel Vertical Boring Milling Machine for Precise Drilling

FAQ

Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price;
2 . Professional R&D team and 25 years export experience;
3 . Exported more than 60 countries;
4 . CE, ISO Certificates;
5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager);
6 . 12 months quality warranty;
7 . Oversea engineers available for problem resolving;

Q: Do you have QC or any safety standards for your machinery?
A: yes, we have established a highly strict quality control department to guanrantee good quality.

Q: What's the MOQ?
A: 1 set (Only some low cost machines will be more than 1 set )

Q: What about the payment terms?
A: 1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment;
2) Irrevocable LC at sight;
3) Western Union, MoneyGram, etc.

Q: How about the warranty?
A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
