Professional Cylinder Block Grinding Milling Machine/Rectificadora de Culatas 3M9735A

Name: Professional Cylinder Block Grinding Milling MachineRectificadora de Culatas 3M9735A
Brand: TIMAC TIMEWAY
Price: 2 USD

Quality Professional Cylinder Block Grinding Milling Machine/Rectificadora de Culatas 3M9735A for sale

Place of Origin : Henan, China

Brand Name : TIMAC TIMEWAY

Condition : New

Video outgoing-inspection : Provided

Machinery Test Report : Provided

Marketing Type : Hot Product 2022

Warranty of core components : 1 Year

Core Components : PLC, Engine, Bearing, Gearbox, Motor, Pressure vessel, Gear, Pump

Warranty : 1 Year, 1 year

Key Selling Points : Competitive Price

Weight (KG) : 2300

Applicable Industries : Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Farms, Retail, Construction works , Energy & Mining

Showroom Location : Philippines, Pakistan, Morocco, Colombia, Kazakhstan, Japan

Product name : cylinder head surface grinding machine

Type : cylinder head and block surface grinding machine

Name : cylinder block surface grinding machine

Machine Type : surface grinder for cylinder heads

Key word : surface grinding cylinder heads

Keywords : cylinder head surface grinding machine

color : Customer Choose

After-sales Service Provided : Online Support

Model : 3M9735A

Packaging Details : wooden case / plywood case

Port : China Port

Supply Ability : 300 Set/Sets per Month

Price : $2,500.00/sets 1-2 sets

MOQ : 1 set

Contact Now

One-Stop Shopping

You can click on the picture to view the products you are interested in

Professional Cylinder Block Grinding Milling Machine/Rectificadora de Culatas 3M9735A

Product Description

Cylinder Block Grinding Machine

Features:

Cylinder Block Grinding & Milling Machine
1. The machine is mainly used for grinding and milling the connecting surface between cylinder body and cylinder cover of every engine (of automobiles, tractors, tanks and ships).
2. Because of the engine be used for long, the connecting surface of cylinder body and cylinder cover would transmute and the engine will working off normal.
3. Working accuracy can be achieved that the connecting surface of cylinder body and cylinder cover be ground or milled.
4. The machine can also grinding the surface of other parts if the electromagnetic chuck be equipped.
5. The machine adopt (1400/700r/min) two-speed motor 1400r/min be used to grind the surface of cylinder body or cylinder cover, which be made by cast-iron material. And 700r/min be used to milled the surface which be made by aluminium material. Emery wheel feeding is manual. Emery wheel feed 0.02mm during hand wheel rotate 1 lattice. Pulley adopt with unloading to make the main spindle only usutain twisting moment.
6. The machine tool working table selects and uses the Y801-4 electric motor drive by rotating, on host face ply, the
potentiometer whorl twists and to gain right feed speed, easy to operate reliable.

Specification

Specification	3M9735Ax130	3M9735Ax150
Max. length of grinding	1300 mm	1500 mm
Max. width of grinding	350 mm	350 mm
Max height of grinding	600 mm	800 mm
Vertical moving distance of grinding head	120 mm	120 mm
Transverse moving speed of working table	40-900 mm/min	30-900 mm/min
Grinding wheel disk diameter	360 mm	360 mm
Spindle speed	1400/700 r/min	1400/700 r/min
Electric motor power cooling down	0.4 Kw	0.4 Kw
Power of the main motor	1.5/2.4 kw	1.5/2.4kw

Machine Details

Positive Comments From Customers

Our Services

1. Free replacing parts available in the warranty period. Cost price replacing parts available beyond the warranty period. 2. Quick action and reply for the technical questions at any time in the whole life of the machine. 3. Overseas after service center available in some region. 4. Engineer overseas service available on the requirement of customer(relative cost born by customer).

Company Introduction

Factory Display：

Factory Profile：

Our factory was established in 2014. It has professional technicians, a research and development team, manufactures and sells CNC equipment and provides professional customized services.Our products are widely used in mold processing, 3C products, agricultural machinery, petroleum machinery, auto parts processing, aerospace industry, etc., selling more than 60 countries and regions in domestic and abroad.

Text Introduction：

Company Profile：

Timeway Machine Tool Co., Ltd. is a professional machine tool manufacturing enterprises, the main products include lathe, milling machine, grinding machine, etc., and according to customer needs we also can design and manufacture various special purpose machines, to provide relative technology upgrading and transformation services in machine tool field.

Customer Visited：

So far, we have received many customers from abroad, and they are all very satisfied with our company and products

Exhibitions：

Since the establishment of the Ministry of Foreign Trade, we have participated in various domestic and international exhibitions such as the Autumn Canton Fair, Beijing Exhibition, Shanghai Exhibition, Moscow, Ethiopia, and Russia, and have maintained long-term friendly cooperative relations with exhibition customers.

FAQ

Q: Why choose TIMEWAY MACHINE?

A: 1 . High quality with competitive price; 2 . Professional R&D team and 25 years export experience; 3 . Exported more than 60 countries; 4 . CE, ISO Certificates; 5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager); 6 . 12 months quality warranty; 7 . Oversea engineers available for problem resolving; Q: Do you have QC or any safety standards for your machinery? A: yes, we have established a highly strict quality control department to guanrantee good quality. Q: What's the MOQ? A: 1 set (Only some low cost machines will be more than 1 set ) Q: What about the payment terms? A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment; (2) Irrevocable LC at sight; (3) Western Union, MoneyGram, etc. Q: How about the warranty? A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.

Professional Cylinder Block Grinding Milling Machine/Rectificadora de Culatas 3M9735A Images
