Valve Guide And Seat Boring Machine The Perfect Solution for High Precision Machining

Name: Valve Guide And Seat Boring Machine The Perfect Solution for High Precision Machining
Brand: Timeway
Price: 3 USD

Quality Valve Guide And Seat Boring Machine The Perfect Solution for High Precision Machining for sale

Table Size (mm) : Other

Table Travel (X) (mm) : 1000 mm

Table Travel (Y) (mm) : 40 mm

Table Travel (Z) (mm) : 9 mm

Number of Axes : 3

Travel (W-axis) (mm) : 1000 mm

Video outgoing-inspection : Provided

Machinery Test Report : Provided

Marketing Type : New Product 2024

Warranty of core components : 1 Year

Core Components : Engine, Motor

Range of Spindle Speed(r.p.m) : 1000 r.p.m

Type : VERTICAL

Condition : New

CNC or Not : Normal

Place of Origin : Henan, China

Brand Name : Timeway

Dimension(L*W*H) : 1750x1150x2200 mm

Weight (T) : 1.6 T

Warranty : 1 Year

Key Selling Points : Competitive Price

Applicable Industries : Machinery Repair Shops, Energy & Mining, Other

Showroom Location : Pakistan, Morocco, Colombia, Kazakhstan

Type of drive system : Air / Electric

Max. length of cylinder head : unlimited

Max. width of cylinder head : 500 mm

Max. height of cylinder head : 450 mm

Clamper rotary angle : 45°

Max. boring diameter : 90 mm

Work head longitudinal floating travel : 1000 mm

Work head cross floating travel : 40 mm

Sphere cylinder travel : 9 mm

Power of spindle : 2.2kw

Price : $3,300.00/sets 1-2 sets

MOQ : 1 set

Contact Now

Product Description

1. Equipped with a new type of air-floating worktable, which is more flexible in cutting heavy cylinder heads.
2. Inclosed leak detecting device and integrated sharpener.
3. Adopt the most advanced T-groove device to fix the air-floating machine head quicklu. Compared with the old vacuum locking device, it saves more compressed air, reduces noise, and makes the performance more stable.

Valve Guide And Seat Boring Machine The Perfect Solution for High Precision Machining

Specification

Specification	VS90
Type of drive system	Air / Electric
Max. length of cylinder head	unlimited
Max. width of cylinder head	500 mm
Max. height of cylinder head	450 mm
Clamper rotary angle	45° / -15°
Max. boring diameter	14 – 90 mm
Work head longitudinal floating travel	1000 mm
Work head cross floating travel	40 mm
Sphere – cylinder travel	9 mm
Power of spindle	2.2 kw
Spindle speed	20-1000 rpm
Spindle travel	200 mm
Max. spindle incination	200 mm
Electric supply	380 V/50 HZ/3 PH or 220 V/60 HZ/3 PH
Required rated air pressure	6 Bar / 87 PSI
Required max. air flow	300 L / Min
Net weight	1680 kg
Machine dimensions( LxWxH)	1750x1150x2200 mm

Packing & Delivery

To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.

One-Stop Shopping

You can click on the picture to view the products you are interested in

Our Services

1. Free replacing parts available in the warranty period. Cost price replacing parts available beyond the warranty period. 2. Quick action and reply for the technical questions at any time in the whole life of the machine. 3. Overseas after service center available in some region. 4. Engineer overseas service available on the requirement of customer(relative cost born by customer).

Company Introduction

Factory Display：

Factory Profile：

Our factory was established in 2014. It has professional technicians, a research and development team, manufactures and sells CNC equipment and provides professional customized services.Our products are widely used in mold processing, 3C products, agricultural machinery, petroleum machinery, auto parts processing, aerospace industry, etc., selling more than 60 countries and regions in domestic and abroad.

Text Introduction：

Company Profile：

Timeway Machine Tool Co., Ltd. is a professional machine tool manufacturing enterprises, the main products include lathe, milling machine, grinding machine, etc., and according to customer needs we also can design and manufacture various special purpose machines, to provide relative technology upgrading and transformation services in machine tool field.

Customer Visited：

So far, we have received many customers from abroad, and they are all very satisfied with our company and products

Exhibitions：

Since the establishment of the Ministry of Foreign Trade, we have participated in various domestic and international exhibitions such as the Autumn Canton Fair, Beijing Exhibition, Shanghai Exhibition, Moscow, Ethiopia, and Russia, and have maintained long-term friendly cooperative relations with exhibition customers.

FAQ

Q: Why choose TIMEWAY MACHINE?

A: 1 . High quality with competitive price; 2 . Professional R&D team and 25 years export experience; 3 . Exported more than 60 countries; 4 . CE, ISO Certificates; 5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager); 6 . 12 months quality warranty; 7 . Oversea engineers available for problem resolving; Q: Do you have QC or any safety standards for your machinery? A: yes, we have established a highly strict quality control department to guanrantee good quality. Q: What's the MOQ? A: 1 set (Only some low cost machines will be more than 1 set ) Q: What about the payment terms? A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment; (2) Irrevocable LC at sight; (3) Western Union, MoneyGram, etc. Q: How about the warranty? A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
