High Equality Mechanical Vertical Slotting Machine with 400 kg Max. Workpiece Weight

  • 1
  • 2

Place of Origin : Henan, China

Brand Name : Timeway

Condition : New

Video outgoing-inspection : Provided

Machinery Test Report : Provided

Marketing Type : Ordinary Product

Warranty of core components : 1 Year

Core Components : Engine, Motor

Dimension(L*W*H) : 1916x1305x1995 mm

Warranty : 1 Year

Key Selling Points : Competitive Price

Power (kW) : 3

Applicable Industries : Building Material Shops, Machinery Repair Shops, Farms, Construction works , Energy & Mining, Other

Showroom Location : Canada, Turkey, United Kingdom, France, Germany, Viet Nam

Weight (KG) : 2200 KG

Max. slotting length : 200 mm

Max. weight of workpiece : 400 kg

Ram movement times : 32, 50, 80, 125 times/min

Ram vertical adjustable stroke : 230 mm

Tool shank size : 25x40 mm

Table diameter : 500 mm

Distance from tool holder to column : 485 mm

Distance from ram nose to table : 320 mm

Table longitudinal travel : 450 mm

Table cross travel : 500 mm

Price : $11,000.00/sets 1-2 sets

MOQ : 1 set

Contact Now

Product Description
High Equality Mechanical Vertical Slotting Machine with 400 kg Max. Workpiece Weight
Specification
Specification
B-200
Max. slotting length:
200 mm
Max. weight of workpiece:
400 kg
Ram movement times:
32, 50, 80, 125 times/min
Ram vertical adjustable stroke:
230 mm
Tool shank size:
25×40 mm
Table diameter:
Φ500 mm
Distance from tool holder to column:
485 mm
Distance from ram nose to table:
320 mm
Table longitudinal travel:
450 mm
Table cross travel:
500 mm
Table longitudinal & cross feed rate:
0.08-1.21 mm
Table rotary feed rate:
0.052-0.783°
Main motor power:
3 kw
Main motor speed:
1430 rpm
Machine weight:
2200 kg
Machine dimensions (L×W×H):
1916×1305×1995 mm
Packing & Delivery
High Equality Mechanical Vertical Slotting Machine with 400 kg Max. Workpiece Weight
High Equality Mechanical Vertical Slotting Machine with 400 kg Max. Workpiece Weight
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
One-Stop Shopping
You can click on the picture to view the products you are interested in
High Equality Mechanical Vertical Slotting Machine with 400 kg Max. Workpiece Weight
High Equality Mechanical Vertical Slotting Machine with 400 kg Max. Workpiece Weight
High Equality Mechanical Vertical Slotting Machine with 400 kg Max. Workpiece Weight
High Equality Mechanical Vertical Slotting Machine with 400 kg Max. Workpiece Weight
High Equality Mechanical Vertical Slotting Machine with 400 kg Max. Workpiece Weight
High Equality Mechanical Vertical Slotting Machine with 400 kg Max. Workpiece Weight
High Equality Mechanical Vertical Slotting Machine with 400 kg Max. Workpiece Weight
High Equality Mechanical Vertical Slotting Machine with 400 kg Max. Workpiece Weight
High Equality Mechanical Vertical Slotting Machine with 400 kg Max. Workpiece Weight
High Equality Mechanical Vertical Slotting Machine with 400 kg Max. Workpiece Weight
High Equality Mechanical Vertical Slotting Machine with 400 kg Max. Workpiece Weight
High Equality Mechanical Vertical Slotting Machine with 400 kg Max. Workpiece Weight
Our Services
1. Free replacing parts available in the warranty period. Cost price replacing parts available beyond the warranty period. 2. Quick action and reply for the technical questions at any time in the whole life of the machine. 3. Overseas after service center available in some region. 4. Engineer overseas service available on the requirement of customer(relative cost born by customer).
Company Introduction
High Equality Mechanical Vertical Slotting Machine with 400 kg Max. Workpiece Weight
Factory Display：
High Equality Mechanical Vertical Slotting Machine with 400 kg Max. Workpiece Weight
Factory Profile：
Our factory was established in 2014. It has professional technicians, a research and development team, manufactures and sells CNC equipment and provides professional customized services.Our products are widely used in mold processing, 3C products, agricultural machinery, petroleum machinery, auto parts processing, aerospace industry, etc., selling more than 60 countries and regions in domestic and abroad.
Text Introduction：
High Equality Mechanical Vertical Slotting Machine with 400 kg Max. Workpiece Weight
Company Profile：
Timeway Machine Tool Co., Ltd. is a professional machine tool manufacturing enterprises, the main products include lathe, milling machine, grinding machine, etc., and according to customer needs we also can design and manufacture various special purpose machines, to provide relative technology upgrading and transformation services in machine tool field.
High Equality Mechanical Vertical Slotting Machine with 400 kg Max. Workpiece Weight
Customer Visited：
So far, we have received many customers from abroad, and they are all very satisfied with our company and products
High Equality Mechanical Vertical Slotting Machine with 400 kg Max. Workpiece Weight
Exhibitions：
Since the establishment of the Ministry of Foreign Trade, we have participated in various domestic and international exhibitions such as the Autumn Canton Fair, Beijing Exhibition, Shanghai Exhibition, Moscow, Ethiopia, and Russia, and have maintained long-term friendly cooperative relations with exhibition customers.
FAQ
Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price; 2 . Professional R&D team and 25 years export experience; 3 . Exported more than 60 countries; 4 . CE, ISO Certificates; 5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager); 6 . 12 months quality warranty; 7 . Oversea engineers available for problem resolving; Q: Do you have QC or any safety standards for your machinery? A: yes, we have established a highly strict quality control department to guanrantee good quality. Q: What's the MOQ? A: 1 set (Only some low cost machines will be more than 1 set ) Q: What about the payment terms? A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment; (2) Irrevocable LC at sight; (3) Western Union, MoneyGram, etc. Q: How about the warranty? A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
