Hydraulic Plate Bending Machine with Arc Down-Adjusting Three Rollers and PLC Control

Name: Hydraulic Plate Bending Machine with Arc DownAdjusting Three Rollers and PLC Control
Brand: TIMAC
Price: 80 USD

Quality Hydraulic Plate Bending Machine with Arc Down-Adjusting Three Rollers and PLC Control for sale

Place of Origin : China

Condition : New

Machine Type : Coiling bending machine, Roll forming machine, Roller-bending machine

Video outgoing-inspection : Provided

Machinery Test Report : Provided

Marketing Type : Hot Product 2019

Warranty of core components : 1 Year

Core Components : PLC, Engine, Bearing, Gearbox, Motor, Pressure vessel, Gear, Pump

Brand Name : TIMAC

Raw Material : Sheet / Plate Rolling

Material / Metal Processed : All kinds of steel sheet

Power : PLC control and Hydraulic

Automation : Semi-automatic

Extra Services : Rolling cone workpiece

Weight (KG) : 6000

Key Selling Points : High-accuracy

Warranty : 1 Year

Applicable Industries : Machinery Repair Shops, Manufacturing Plant

Showroom Location : Peru, Kenya, South Korea, Chile

After-sales Service Provided : Engineers available to service machinery overseas

Color : According to customer's require

Max. thickness of rolling plate : 12mm

Max. width of rolling plate : 2000mm

Voltage : 380V/50HZ

roller moving type : Hydraulic drive

Main motor power : 11kw

Width and thickness of rolling plate : Customization

Control type : PLC

Structure : Lower rollers arc adjustment

Packaging Details : Wood case or wooden pallet

Port : China Port

Supply Ability : 200 Set/Sets per Year

Price : $80,000.00/sets >=1 sets

MOQ : 1 set

Contact Now

Product Description

Plate Rolling Machine

Hydraulic Plate Bending Machine with Arc Down-Adjusting Three Rollers and PLC Control

Feature

1. The upper roller is fixed. The two lowers can move up and down in arc way around fixed roller. It can finish pre-bending and rolling by feeding once.
2. The three rollers are driving-roller. It can prevent skidding while rolling thin steel plate.
3. It's controlled by micro-machine and has digital display, simply operation and high efficiency.
4. With compact structure, it is economical and pratical and fit for rolling thin and medium plate.

Specification

Specificaitons	Max. thickness (mm)	Max. pre-bending thickness (mm)	Max. width (mm)	Full loading min. bending dia.(mm)	Upper roller diameter (mm)	Bottom roller diameter (mm)	Rolling speed (m/min)	Main motor power (kw)
HTR-6*2000MA	6	4	2000	600	220	210	5.5	5.5
HTR-8*2500MA	8	6	2500	650	240	240	5	11
HTR-12*2000MA	12	8	2000	700	250	250	5	11
HTR-15*2000MA	15	10	2000	700	300	300	5	15
HTR-16*2500MA	16	12	2500	800	330	320	5	18.5
HTR-20*2000MA	20	16	2000	800	320	320	4.5	22
HTR-20*2500MA	20	16	2500	900	350	340	4.5	22
HTR-25*2000MA	25	20	2000	850	330	330	4.5	22
HTR-25*3000MA	25	20	3000	1300	460	460	4	30
HTR-30*2000MA	30	25	2000	1300	420	420	4	30
HTR-40*2000MA	40	32	2000	1500	550	550	3	37

Client feedback

Our Services

1. Free replacing parts available in the warranty period. Cost price replacing parts available beyond the warranty period. 2. Quick action and reply for the technical questions at any time in the whole life of the machine. 3. Overseas after service center available in some region. 4. Engineer overseas service available on the requirement of customer(relative cost born by customer).

Company Profile

Factory Display：

Factory Profile：

Our factory was established in 2014. It has professional technicians, a research and development team, manufactures and sells CNC equipment and provides professional customized services.Our products are widely used in mold processing, 3C products, agricultural machinery, petroleum machinery, auto parts processing, aerospace industry, etc., selling more than 60 countries and regions in domestic and abroad.

Text Introduction：

Company Profile：

Timeway Machine Tool Co., Ltd. is a professional machine tool manufacturing enterprises, the main products include lathe, milling machine, grinding machine, etc., and according to customer needs we also can design and manufacture various special purpose machines, to provide relative technology upgrading and transformation services in machine tool field.

Customer Visited：

So far, we have received many customers from abroad, and they are all very satisfied with our company and products

Company Video

FAQ

Q: Why choose TIMEWAY MACHINE?

A: 1 . High quality with competitive price; 2 . Professional R&D team and 25 years export experience; 3 . Exported more than 60 countries; 4 . CE, ISO Certificates; 5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager); 6 . 12 months quality warranty; 7 . Oversea engineers available for problem resolving; Q: Do you have QC or any safety standards for your machinery? A: yes, we have established a highly strict quality control department to guanrantee good quality. Q: What's the MOQ? A: 1 set (Only some low cost machines will be more than 1 set ) Q: What about the payment terms? A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment; (2) Irrevocable LC at sight; (3) Western Union, MoneyGram, etc. Q: How about the warranty? A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
